Design Preparation
Part of POD design preparation
Preparing artwork for the required print dimensions
Find the exact POD print area, calculate resolution at final size, use safe areas and bleed correctly, and inspect the uploaded file.
Before exporting, find the file dimensions for the exact product, print area and variant. Check raster resolution at the size the artwork will actually print. Keep important details within the safe area, then inspect the uploaded result. A “300 DPI” label alone does not show that the file has enough pixels.
Read the product’s file rules
Identify the supplier product and print position, then check its maximum print area, recommended file size or resolution, accepted formats, safe area and any bleed. Repeat for another print position or supplier. Requirements vary by product and print area, so check current product guidance before exporting.
The print area is the maximum space available. The safe area keeps essential details away from edges where placement or trimming may vary. Bleed is extra background coverage that is trimmed off after printing, so the ink still reaches the edge if the cut shifts slightly.
As a worked benchmark, Gelato’s requirements for print-ready PDF uploads ask for a 4 mm bleed on all sides and a safe area starting at least 4 mm inside the trim line, with images at 150 to 300 dpi at actual size. For framed prints, the frame covers about 4–5 mm on each side.
For apparel printed by direct-to-garment (DTG), Gelato asks for PNG or JPEG files at a minimum of 150 DPI and recommends 300 DPI for the best quality. Use PNG when the design needs a transparent background, and design in the sRGB colour profile.
Where artwork reaches an edge, extend the background through any required bleed and keep text and other important elements inside the safe area. A small centred chest design need not fill the entire print area.
Calculate resolution at final size
For a raster image, divide its pixel width by the intended print width in inches. Repeat for height and compare the lower pixels-per-inch result with the chosen product’s requirement. Convert centimetres to inches by dividing by 2.54.
Working in millimetres, pixels = millimetres × (resolution ÷ 25.4). For example, a design 10 centimetres wide needs about 590 pixels across at 150 DPI and about 1180 pixels at 300 DPI. Size the export from those figures, then check the height the same way.
Changing its DPI metadata does not add detail. Increasing the pixel count of a low-resolution image will not improve the print either, so start from artwork created at the required resolution.
Compare the result with the resolution specified for the chosen product and print area. In Gelato’s design editor, an uploaded image that is not suitable for high-quality printing triggers a resolution warning, although that warning does not cover PDF and SVG files.
Key Print Dimensions and Resolution Guidelines
- Preferred File Format (Transparency)
- PNG
- Colour Space
- sRGB
Use the available template
Where a template is available, use it to position the design. Keep lettering, faces and other essential details within its safe boundary. Extend backgrounds through required bleed.
Check seams, openings and size variants where the printable area changes. If no template is supplied, use the product’s stated print boundaries and requirements.
Hide or remove template guides before export. Inspect the exported file for clipped details, stray pixels and an unwanted opaque background. Use a file format accepted for the product, and check its transparency requirements if the artwork needs a transparent background.
Formats differ by route: Gelato’s design editor takes a PDF, PNG, JPG or HEIC file as a base, while its print-ready PDFs should be exported as PDF/X-4 with fonts embedded or converted to outlines.
Inspect the upload
Upload the final export to the correct product and print area. Check placement, any file-quality warning and the offered variant previews. Record the product, file version, intended print size and print position. If you change the artwork’s scale, product or variant, repeat the resolution and placement checks.
